Printing onto plastic films for flexible packaging is among the most demanding applications of flexographic (flexo) presses. Films are non-porous, dimensionally sensitive, and often chemically inert; at the same time, the market demands sharp graphics, multi-color registration, fast throughput, and regulatory compliance (especially for food packaging).
Compared to paper or board substrates, plastic films bring a distinct set of challenges:
Nonporous, low surface energy：Films like BOPP, PET, CPP, PE, PA (nylon), multilayer laminates are smooth and chemically inert. They do not absorb ink; adhesion depends entirely on surface wetting and ink-film bonding.
Dimensional stability / web stretch：Under tension, films may stretch or relax, affecting registration. Thermal expansion, residual stress, and reel memory can exacerbate this.
Thin gauge & thickness variability：Film gauges (e.g. 12–100 µm) are thinner than paperboard and may have thickness variation; even slight fluctuations can affect pressure, dot gain, and ink transfer.
Ink “blocking” and setoff：Because films don’t absorb ink, wet ink may transfer to the back side or adjacent layers (especially in roll winding) if drying is inadequate.
Drying constraints：Since water or solvent can’t penetrate, drying must remove solvent/water rapidly without overheating or damaging the film.
Adhesion, migration, and delamination：Especially in multi-layer or laminated structures, inks must resist delamination, chemical exposure, heat, and mechanical stress.
Print defects unique to film：Issues like ghosting, chasing, mottling, bridging, and over-inking are more acute on film substrates.
Because of these constraints, printing high-quality, multi-color film packaging requires careful engineering and process design.
Despite the challenges, flexo has become the leading print method for flexible packaging films, for several reasons:
Wide substrate compatibility：Flexo uses relief plates and can print on nearly any flexible substrate, including films, foils, laminates, and composites
High speed, roll-to-roll operation：Flexo presses can sustain high web speeds, matching the throughput demands of flexible packaging production.
Modular drying & inline finishing：Flexo lines often incorporate modular dryers, corona treaters, chillers, lamination, and slitting, offering a more integrated workflow.
Better environmental ink options：Modern flexo presses support water-based, UV, and hybrid ink systems, enabling more eco-friendly packaging (if matched appropriately).
Short-web path, reduced waste design：Some presses (e.g. top-loading, short web path models) reduce makeready waste — vital for thin film jobs. GREENPRINT’s HRYC series, for example, is described as “short web path to minimize waste.”
However, to succeed, the press must be precisely designed and configured to address film-specific issues.
The anilox roller is central to ink metering and transfer in flexo. On film printing, proper selection and control of the anilox is absolutely critical.
Cell volume vs. Density：You want enough total cell volume to carry a uniform ink film, but not so much that excessive ink floods or drying issues occur.
Cell type / shape：Tri-hex, quadrangular, and other cell shapes differ in their release behavior. Smooth-walled, well-formed cells help in consistent transfer.
Line count (lpi / L/cm)：Higher line count (fine cells) yields better detail but lower ink volume; lower line count (coarse) gives bigger volume but poorer detail. Many converters select a compromise based on job type.
Ink viscosity & rheology：The ink must be tuned to flow into the cells properly but not flood. Improper viscosity can cause smearing, speckling, or incomplete transfer.
Doctor blade / chambered doctor systems：Proper pressure and blade selection help ensure the anilox cells are cleanly metered and avoid over-supply or under-supply of ink.
Closed-loop control：Some systems measure ink layer thickness (e.g. via spectrophotometry or on-press sensors) and adjust ink pump or pressure.
Recipe-based switching：Job memory allows switching between anilox/ink combinations when jobs change, reducing manual trial-and-error.
Temperature control：Ink temperature influences viscosity, so controlling ink temperature (in tank, lines, and anilox) helps maintain consistency.
Use gradual ramping when changing ink volumes (don’t jump extremes).
Clean the anilox frequently to prevent cell plugging or dried ink interference.
For multi-color jobs, ensure consistent matched volumes across colors to minimize registration errors.
Selecting an optimal anilox setup is a balancing act among detail, ink usage, drying capacity, and adhesion.
Because film substrates are inert, enhancing surface energy is essential to achieve good adhesion. Below are key techniques and considerations.
Purpose: increase surface energy (make nonpolar film more polar) to allow better wetting of ink.
Inline treatment: Many flexo lines include corona treater modules just before the first print station.
Treatment level: Typical film requires ~38–48 dynes or higher, but optimal level depends on ink type.
Aging effect: After treatment, the film loses its increased energy over time; timely printing is essential.
In some high-demand applications, especially in films with barrier layers or topcoats, a primer or adhesion layer helps bonding. The primer must be compatible with subsequent inks and sealing layers.
Oils, plasticizers, slip agents, and dust on film surfaces can hinder adhesion. Pre-cleaning (e.g. corona + web cleaner, air knifes, static eliminators) is common.
Static discharge and ionizers reduce dust attraction and particle contamination.
Use ink additives (e.g. adhesion promoters, wetting agents, crosslinkers) tailored to the film substrate.
For food packaging, ensure additives comply with regulatory constraints.
Maintain pH, solvent balance, and mixing to keep ink in optimal adhesion state.
Uniform pressure between plate and impression cylinder helps ensure complete ink transfer without crushing or smearing.
Avoid excessive pressure which may squeeze ink or distort the film.
By combining surface treatment, proper cleaning, and tuned ink chemistry, adhesion can meet demanding performance expectations (e.g. tape tests, delamination tests, rub resistance).
Producing sharp, multi-color images on film requires both mechanical precision and a drying infrastructure designed for non-absorptive materials.
Web tension control: Precise tension zones and feedback ensure the film runs flat and without lateral drift.
Short web paths: Reducing the path between color stations helps reduce register drift. Many presses (e.g. GREENPRINT’s HRYC) are designed with short paths.
Servo drives & synchronized motion: Use high-precision servo systems to coordinate rollers, registration sleeves, and servo motors.
Pre-registration & auto alignment: Some presses allow alignment before full start running to reduce trial-and-error.
Because film does not absorb moisture, drying must fully evaporate solvent or cure ink rapidly and uniformly:
Inter-station dryers: Hot-air, IR, or radiant heaters between stations to partially fix ink.
Bridge dryers / tunnel dryers: After the last station, longer drying tunnels ensure full cure before winding.
Cooling / chill drums: Immediately after drying, cool the film before winding to prevent blocking.
Infrared / UV / electron-beam (EB): Depending on ink type, UV or EB curing can instantly fix ink layers.
Ventilation & airflow design: Uniform airflow avoids hot spots; balanced exhaust systems keep solvent vapor under control.
Ink layering: Each ink layer must be sufficiently dried before the next to prevent mixing or offset.
Dot gain control: On thin films, dot gain is sensitive to pressure and drying; proper calibration is essential.
Ghosting & bridging mitigation: Monitor and avoid ghosting by optimizing ink supply, drying, and the interplay among colors.
Blocking avoidance: Control ink volume, dryness before winding, and winding tension to avoid setoff.
An effectively engineered drying and registration system is often the differentiator between “good enough” and “exceptional” film flexo quality.
When printing flexible packaging for food or pharmaceutical applications, compliance and safety are non-negotiable. Flexo printing must align with a number of standards and practices.
FDA / EU regulations: In many jurisdictions, contact or near-contact packaging materials must adhere to migration limits, use compliant inks/additives, and satisfy food-contact approvals.
Good Manufacturing Practice (GMP): The printing process must avoid contamination, cross-contamination, and ensure traceability.
Migration & barrier testing: For multi-layer films, ink components must not migrate into food beyond allowable thresholds.
Certification & documentation: Suppliers often require documentation of raw materials, safety data sheets, and migration testing records.
Use only food-grade raw materials (pigments, resins, additives) certified for the target markets.
Avoid heavy metals, prohibited solvents, or uncontrolled monomers.
For water-based systems, ensure microbial stability and preservative safety.
In laminated structures, printed layers may be laminated or thermally sealed; inks must be compatible with adhesives & sealant layers.
Ink layers should not interfere with barrier performance (e.g. oxygen, moisture).
Track lot numbers, perform in-line QC (color, adhesion, set-off)
Use inline inspection systems (camera, spectrophotometer) to detect defects immediately.
Conduct validation runs and audits to satisfy clients or regulatory bodies.
Flexo as a technology is quite compatible with food packaging requirements — but only when diligent design and material control are in place.
Printing on plastic film substrates for flexible packaging is among the most technically challenging tasks in the packaging world. Success in this domain requires:
Precise design of the flexo press (short web paths, robust registration, modular drying)
Thoughtful selection of anilox geometry and control of ink volume
Effective surface treatment and adhesion strategies
Well-engineered multi-color alignment and drying systems
Strict adherence to food safety and regulatory constraints
Partnering with a supplier who understands film-specific demands
Because film printing is unforgiving of errors, choosing a vendor that is experienced, innovative, and focused on sustainability is crucial. Zhejiang GREENPRINT Machinery Co., Ltd. stands out as a candidate: they offer machines with short-path design, precision features, and environmental alignment with water-based ink systems. Exploring their product lines, requesting case studies, and engaging with their technical team may help you identify a machine that meets your advanced film packaging needs.
